CS CRIE’s Mesh Filter Seal for 96-well microplate is a seal type cell strainer, provides rapid and easy filtration on 96-well microplate for many applications – e.g. sample preparation prior to flow cytometry analysis, removal of debris or cell aggregates in cell culture, etc.
Products
CSCRIE products introduction
Mesh Filter (cell strainer) Seal for 96-well microplate
Mesh filter seal for 96-well microplate supports rapid and easy filtration from multiple samples!Struggling with cell and sample filtration on 96-well microplates with traditional cell strainers?
our Microplate Mesh filter seal for 96-well microplate definitely supports rapid and easy sample filtration.
Common problems on sample filtration vs. Our solution for flow cytometry and cell culture
Common problems to prepare single cell supension samples for flow cytometry and cell culture are :
✓ Painful filtration for multiple samples
✓ Too much work and time
✓High total cost
To solve such problems,
we offer great solution for you : Microplate mesh seal for 96 well!
✓Efficiently process multiple samples
✓Low risk of contamination among wells
✓Reduce the unit cost of experiment
Key Features
1. Easy to attach a seal to microplate
If failed, you can remove and attach the seal again.
2. Economical : You can cut a seal to meet your required number of wells
You can cut the seal following to perforations. You can keep the rest of seal to next chance.
3. Highly homogeneous mesh pores
Uses highly homogeneous mesh pores of 30, 70 and 100 um sizes
Comparison before and after cell filtrationSample : HEK293 cell
Before filtration
After filtration
VOICE
Global Center for Science and Engineering
Dr. Chihiro Nozaki
This is exactly what I was looking for! The quick response from inquiry to trial production surprised me with the product that is more than I imagined.
→Special page for interview with Dr. Nozaki
Stem cell biologist at a private university (male in his 40s)
Compared to the conventional method, both cost and time were greatly reduced, which was very helpful. Experiment failures by students were eliminated, and the flow cytometry experiment went this way.
DETAILS
Individually packed. Gamma-ray sterilized
| Product name | Microplate mesh seal for 96 well |
|---|---|
| Materials | Sheet: PET Mesh: Polyester fiber Adhesive: Silicone |
| Size | 80 mm x 122 mm x 0.4 mm thickness |
| Pore size | 30, 70 and 100 um |
| Product Code | Description | Q’ty | Price |
| R-CSC001-01A | Microplate mesh seal for 96 well, 30 µm | 1 piece | Contact us |
| 5 pieces | |||
| 20 pieces | |||
| R-CSC018-01 | Microplate mesh seal for 96 well, 70 µm | 1 piece | Contact us |
| 5 pieces | |||
| 20 pieces | |||
| R-CSC019-01 | Microplate mesh seal for 96 well, 100 µm | 1 piece | Contact us |
| 5 pieces | |||
| 20 pieces |
Product video
HOW TO USE
96-well use -1
Remove the back sheet.
96-well use -2
Place the mesh seal on the microplate according to the well patern. * Even if failure, it can be re-pasted.
96-well use -3
Drop sample with the pipette slightly angled.
8-well use -1
Cut along the perforations with scissors.
*Can also be used with 1 well.
8-well use -2
Remove the back sheet and paste it to the microplate.
8-well use -3
Drop sample with the pipette slightly angled.
Tips for dropping sample on the mesh seal for 96-well microplate
OTHERS
Cell culture plate
Microfluidic chip
Need other pore size or customized ones? Just contact us!
